About this item
GD01
The GD01 is a compact LCD display designed to be mounted on the left side of the handlebar. It is compatible with handlebars with a diameter of 22.2mm, measuring just 83mm x 48mm x 48mm, and offers clear visibility.
S700
The S700 is a highly visible LCD display designed to be mounted in the center of the handlebar. Measuring 84.7mm x 121mm x 79mm, it supports large font display for easy readability. It also comes with a button accessory, which can be mounted on either the left or right side of the handlebar—compatible with handlebars that have a 22.2mm diameter.
M210C
The M210C is an ultra-compact color TFT display, specifically designed for handlebars with a diameter of 22.2mm. It measures a mere 71.8mm × 25.6mm × 42.2mm, and is equipped with a 1.6-inch screen with a resolution of 170×320, ensuring clear visibility. Its compact size keeps the handlebar neat and uncluttered, and it can be mounted on either the left or right side of the handlebar. Installation is simple: there is no need to remove the handlebar grip—just fasten the two half-rings around the handlebar and secure them with screws.
Note: The M210C display is only compatible with the controller model A2PA. You can check the controller model in the “Device Information” section of the APP.
M210CTL
The M210CTL is an ideal TFT instrument. It integrates a thumb throttle function while retaining the ultra-compact size of the M210C. With dimensions of just 79.6mm × 49.5mm × 52mm, it is compatible with handlebars with a diameter of 22.2mm. Due to the built-in thumb throttle, it must be mounted on the left side of the handlebar. Installation is straightforward: there is no need to remove the handlebar grip—simply fasten the two half-rings around the handlebar and secure them with screws.
If you prefer a cleaner and more sleek appearance for your handlebar, the M210CTL is your ideal choice.
Note: The C810 display is only compatible with the controller model A2PA. You can check the controller model in the “Device Information” section of the APP.
C310
The C310 is a compact TFT display designed for mounting on the left side of the handlebar. It is compatible with handlebars with a diameter of 22.2mm, measuring just 50mm × 90mm × 47mm. Equipped with a 2.4-inch screen and boasting a resolution of 240×320, it ensures clear visibility.
Note: The C310 display is only compatible with the controller model A2PA. You can check the controller model in the “Device Information” section of the APP.
C810
The C810 is a split-type color TFT display, consisting of two independent components: the display screen and the control buttons. The display screen is mounted in the middle of the handlebar, allowing you to quickly access system information and other data; the control buttons can be installed on either the left or right side of the handlebar, enabling convenient gear adjustment. Measuring just 95.4mm × 79.4mm × 58.5mm, it is equipped with a 3.0-inch screen with a resolution of 240×320, ensuring clear visibility.
It should be noted that while the display screen is compatible with handlebars of 22.2mm, 25.4mm, and 32mm in diameter, the control button component can only be mounted on handlebars with a diameter of 22.2mm.
Note: The M210CTL display is only compatible with the controller model A2PA. You can check the controller model in the “Device Information” section of the APP.
